Victron Energy LifePO4 Lithium Batteries NG Series
Victron Energy LifePO4 Lithium Batteries NG Series
Please call to verify this item is currently in stock at the store or warehouse. Online availability does not guarantee in-store availability.
Usually ready in 5+ days.
We will call you when your order is ready for pickup.
Warehouse transfers may take between 3–5 business days.
- Free shipping on most orders over $99 across Canada exceptions apply
- Description
Victron Energy – Lithium LifePO4 NG Battery
Technology
LiFePO4 (12V/300Ah)
Group Size
N/A
Dimensions (H x W x D)
8.1 X 17.6 X 8.1 in
206 X 447 X 205 mm - (12.8V/ 300Ah NG)
9.3 X 13.4 X 6.3 in
235 X 341 X 160 mm - (12.8V/ 200Ah NG)
9.3 X 7.8 X 6.3 in
235 X 197 X 160 mm - (12.8V/ 100Ah NG)
Weight
64 lbs / 29 kg - (12.8V/ 300Ah NG)
42 lbs / 19 kg - (12.8V/ 200Ah NG)
20 lbs / 9 kg - (12.8V/ 100Ah NG)
Voltage
12V
Capacity (Ah)
300 Ah - (12.8V/ 300Ah NG)
200 Ah - (12.8V/ 200Ah NG)
100 Ah - (12.8V/ 100Ah NG)
Capacity (kWh)
3.84 kWh - (12.8V/ 300Ah NG)
2.56 kWh - (12.8V/ 200Ah NG)
1.28 kWh - (12.8V/ 100Ah NG)
Victron Energy Lithium NG batteries are Lithium Iron Phosphate (LiFePO4 or LFP) batteries available with a nominal voltage of 12.8 V, 25.6 V and 51.2 V in various capacities. They can be connected in series, parallel and series/parallel so that a battery bank can be built for system voltages of 12 V, 24 V or 48 V.
The maximum number of batteries in one system is 50, which results in a maximum energy storage of
192 kWh in a 12 V system and up to 384 kWh in a 24 V and 48 V system.
Key features:
Integrated shunt
The battery data (battery voltage, current and temperature) are transmitted to the BMS and evaluated there, i.e. to calculate the state of charge, which can then be read out via VictronConnect or a GX communication centre, or to create and issue specific warnings and alarms.
Automatic setup, monitoring and control via VictronConnect App or a GX device and the VRM Portal
All battery parameters are managed by the BMS automatically. The BMS automatically detects the
system voltage and the number of batteries in parallel, series and series/parallel connection. The BMS (from now on Lynx Smart BMS NG 500 A/1000 A, further models to follow) is mandatory and must be purchased separately.
Monitoring and control take place via VictronConnect (every BMS model has Bluetooth), a GX communication centre or the VRM Portal. You can view battery parameters such as cell status, cell voltages, battery current and temperatures in real-time. The battery firmware is automatically updated by the BMS.
Easy bracket mounting
Mounting brackets make the installation easier and ensure that the battery is optimally secured against
slipping and tipping over.
Increased ingress protection (IP-rating)
The Lithium NG batteries are effectively sealed against dust and can withstand low-pressure water jets, making them suitable for environments where exposure to dust and water is a concern.
Low self-discharge rate
The self-discharge rate has been significantly improved and is now a maximum of 2 % of the battery capacity per month. A low self-discharge rate contributes to the overall performance, longevity, and reliability of the NG batteries.
CYCLE LIFE (capacity ≥ 80 % of nominal)
80 % DoD 2500 cycles
70 % DoD 3000 cycles
50 % DoD 5000 cycles
